Convenient Functionality
When you want to view waveforms, numerical values, and
comments at the same time
You want to view waveforms and numerical values at the same time. You want to
display comments that identify the data.
Switching the waveform screen
See “Waveform display” in the Instruction Manual.
You can switch the waveform screen with the WAVE key.
This feature also lets you display numerical values and comments along with waveforms.
Waveform
Numerical values
Comments
When you want to read values from waveforms
You want to read values from waveforms. You also want to ascertain the potential
dierence or time dierence between two points.
A/B cursors
See “1.13 Using the A/B Cursors” in the Instruction Manual.
The A/B cursors let you read measured values and times from waveforms.
You can also read the potential dierence and time dierence between the A cursor and the
B cursor.
Values read with A/B cursors
B cursor
A cursor
