Overview
1.1 Instrument Overview and Features
The LR8450/LR8450-01 is a multichannel logger that can measure physical properties such as
temperature, voltage, and strain when used in combination with measurement modules.
Two categories of measurement modules are available: plug-in modules that can be plugged
directly into the instrument and wireless modules that can send data wirelessly.
Choose the modules that are right for your application from 10 di󰀨erent
types.
The LR8450 can accommodate plug-in modules.
The LR8450-01 is capable of communications with not only plug-in modules but also
wireless modules.
Recommended modules
Feature Plug-in modules Wireless modules
Record temperature at a sampling interval of
10 ms (using thermocouples)
U8550 LR8530
Record temperature with a high degree of
precision (using resistance temperature detectors)
U8551 LR8531
Record multiple channels of temperature data
(using thermocouples)
U8552 LR8532
Record voltage data at a sampling interval of 1 ms U8553 LR8533
Record strain data at a sampling interval of 1 ms U8554 LR8534
See “Plug-in modules” (p. 30) and “Wireless modules” (p. 31).
Add or remove modules according to the number of channels.
Both the LR8450 and LR8450-01 can accommodate up to four plug-in modules.
The LR8450-01 can also record data using only wireless modules, even if no plug-in
modules have been installed.
Number of modules and channels that can be used
Model number
Plug-in
modules
Wireless
modules
Number of channels that can be
measured
LR8450 4 – 120
LR8450-01 4 7 330 (plug-in: 120; wireless: 210)
See “2.1 Connecting Plug-in Modules” (p. 38).
1 Overview
Overview
HIOKI LR8450A963-02
