DIGI*TRAC Annunciator User’s Guide
10
Velocity Assignment
If you are using Velocity, you can assign an operator the ability to use
the Annunciator in one of two ways:
● Define a Function Group
● Define a user credential through Enrollment Manager
Creating a Function Group is the best way if you plan to assign
Annunciator privileges to more than one user.
Function Group Assignment
To assign Annunciator privileges for a group through Function Groups:
1. From the Velocity system tree, select the Function Groups folder.
A list of all currently-defined function groups and the Add New
Function Group button appear in the right hand Components
pane.
2. Either double click the Add New Function Group button to create
a new function group, or double click an existing function group.
The Function Group Properties dialog box appears.
3. If this is a new function group, enter a new function group name
in the Name field. If this is an existing function group, a name
already appears.
4. Click the Add... button to add the required code extension to this
function group. The Define Extension dialog box appears.
5. In the “Extension Digits” field, enter one or two digits.
6. In the “Function Category” field, select Alarm from the pull-down
option list.
7. Fr om t he “Function” field, select Alarm Cancel from the pull-down
option list.
8. From the “Controller” combo box, select the currently-defined
controller to which this extension code applies.
9. From the “Control Zone” combo box, select the currently-defined
control zone or master control zone during which this extension
digit applies.
10. Click Add to register the new extension digit in the lower window.
11. Click OK to return to the Function Group Properties dialog box.
12. Click OK to return to the main menu.
