HIRSCH DIGI TRAC User Manual

DTA001-0602
1
Introduction
The DIGI*TRAC Annunciator (DTA) is used to monitor basic security
functions—such as alarm, input, and relay status. It provides a local
display of critical information near or outside the protected area. The
DTA is ideal for lobbies and other passages outside of the secured
area where a qualified individual can confirm the protected area is
secure.
On the back of the Annunciator is an integrated MATCH2 board that
communicates with the controller using the same digital channel as
both the ScramblePad and MATCH.
Figure 1: DIGI*TRAC Annunciator – Side View
The front of the Annunciator includes both a four-line, 20-character
LCD display and four status request buttons.
The status request buttons are smart keys that change their meaning
according to the current dialog displayed on the LCD screen above
the keys.
Integrated
MATCH-2
