24
Installation BAT867-R
Release
06
08/2018
2.3 Installing the antennas
The devices have 2 Reverse SMA connectors for connecting external
antennas.
Note: When using 2 antennas type BAT-ANT-RSMA-2AGN-R, you must
align each antenna in another spatial direction (x-y) so that both antennas are
arranged at right angles to each other.
When mounting only 1 antenna, insert a terminating resistor into the unused
socket. You can obtain terminating resistors as accessory.
See “Accessories” on page 44.
Note: Device variants with the configuration characteristic value Z contain a
pre-mounted terminating resistor SMA to ANT2 for RSMA ANT connectors.
You will find information on setting the transmit power in chapter “Configuring
the transmit power” on page 31.
2.4 Connecting the terminal blocks
Note: The supply voltage is connected to the device casing through
protective elements exclusively.
WARNING
ELECTRIC SHOCK
Before connecting the electrical wires, always verify that the requirements
listed are complied with.
See “Requirements for connecting electrical wires” on page 7.
See “Requirements for connecting the supply voltage” on page 8.
Never insert sharp objects (small screwdrivers, wires, etc.) into the
connection terminals for electric conductors, and do not touch the terminals.
Failure to follow this instruction can result in death, serious injury, or
equipment damage.
