Hirschmann BAT867-R - IEEE 802.11 A; IEEE 802.11 N

Installation BAT867-R
Release 06 08/2018
39
8.5.3 IEEE 802.11a
8.5.4 IEEE 802.11n
IEEE 802.11a
Frequency range 5.180 GHz to 5.825 GHz
Bandwidth 20 MHz
Data rate Transmit power Receiving sensitivity
6 Mbit/s 23 dBm 94 dBm
9 Mbit/s 23 dBm 94 dBm
12 Mbit/s 23 dBm 92 dBm
18 Mbit/s 23 dBm 90 dBm
24 Mbit/s 23 dBm 86 dBm
36 Mbit/s 21 dBm 84 dBm
48 Mbit/s 19 dBm 81 dBm
54 Mbit/s 18 dBm 80 dBm
Table 7: IEEE 802.11a, frequency range 5.180 GHz to 5.825 GHz, bandwidth
20 MHz
IEEE 802.11n
Frequency range 2.412 GHz to 2.472 GHz
Bandwidth 20 MHz
Coding Transmit power Receiving sensitivity
MCS 0 / 8 24 dBm 93 dBm
MCS 1 / 9 24 dBm 91 dBm
MCS 2 / 10 24 dBm 89 dBm
MCS 3 / 11 23 dBm 84 dBm
MCS 4 / 12 23 dBm 83 dBm
MCS 5 / 13 23 dBm 78 dBm
MCS 6 / 14 21 dBm 78 dBm
MCS 7 / 15 19 dBm 76 dBm
Table 8: IEEE 802.11n, frequency range 2.412 GHz to 2.472 GHz, bandwidth
20 MHz
IEEE 802.11n
Frequency range 2.412 GHz to 2.472 GHz
Bandwidth 40 MHz
Coding Transmit power Receiving sensitivity
MCS 0 / 8 23 dBm 92 dBm
MCS 1 / 9 23 dBm 88 dBm
Table 9: IEEE 802.11n, frequency range 2.412 GHz to 2.472 GHz, bandwidth
40 MHz
