Hirschmann BAT867-R - Page 40

40
Installation BAT867-R
Release 06 08/2018
MCS 2 / 10 23 dBm 85 dBm
MCS 3 / 11 22 dBm 82 dBm
MCS 4 / 12 22 dBm 79 dBm
MCS 5 / 13 22 dBm 75 dBm
MCS 6 / 14 21 dBm 75 dBm
MCS 7 / 15 19 dBm 73 dBm
IEEE 802.11n
Frequency range 5.180 GHz to 5.825 GHz
Bandwidth 20 MHz
Coding Transmit power Receiving sensitivity
MCS 0 / 8 22 dBm 93 dBm
MCS 1 / 9 22 dBm 90 dBm
MCS 2 / 10 22 dBm 87 dBm
MCS 3 / 11 21 dBm 83 dBm
MCS 4 / 12 21 dBm 80 dBm
MCS 5 / 13 20 dBm 77 dBm
MCS 6 / 14 19 dBm 74 dBm
MCS 7 / 15 17 dBm 73 dBm
Table 10: IEEE 802.11n, frequency range 5.180 GHz to 5.825 GHz, bandwidth
20 MHz
IEEE 802.11n
Frequency range 5.180 GHz to 5.825 GHz
Bandwidth 40 MHz
Coding Transmit power Receiving sensitivity
MCS 0 / 8 21 dBm 90 dBm
MCS 1 / 9 21 dBm 88 dBm
MCS 2 / 10 21 dBm 85 dBm
MCS 3 / 11 20 dBm 82 dBm
MCS 4 / 12 20 dBm 79 dBm
Table 11: IEEE 802.11n, frequency range 5.180 GHz to 5.825 GHz, bandwidth
40 MHz
IEEE 802.11n
Frequency range 2.412 GHz to 2.472 GHz
Bandwidth 40 MHz
Coding Transmit power Receiving sensitivity
Table 9: IEEE 802.11n, frequency range 2.412 GHz to 2.472 GHz, bandwidth
40 MHz
