Hirschmann BAT867-R - 9 Scope of Delivery, Order Numbers and Accessories

44
Installation BAT867-R
Release 06 08/2018
9 Scope of delivery, order numbers and
accessories
 Scope of delivery
Figure 2: Scope of delivery for device variants featuring Configuration with the
characteristic value 9
Figure 3: Scope of delivery for device variants featuring Configuration with the
characteristic value Z
 Accessories
Note that products recommended as accessories may have different
characteristics to those of the device, which may limit the application
range of the overall system. For example, if you add an accessory with
IP20 to a device with IP65, the degree of protection of the overall system
is reduced to IP20.
For reliable receive power and transmission power, you require antennas
that pertain to your application case.
The "Antenna Guide" document provides an overview of the antennas
that can be used as well as the suitable antenna accessories.
This document is available for download as a PDF file on the Hirschmann
product pages (www.hirschmann.com).
Number Article
1 × Device
1 × General safety instructions
1 × EU Declaration of Conformity
1×
1×
premounted
2-pin terminal block for the supply voltage
Number Article
1 × Device
1 × General safety instructions
1 × EU Declaration of Conformity
1×
premounted
2-pin terminal block for the supply voltage
1×
premounted
Terminating resistor SMA to ANT2 for RSMA ANT connectors
2×
included
Antenna type BAT-ANT-RSMA-2AGN-R for RSMA ANT connectors
Other accessories Order number
2-pin terminal block (50 pieces) for supply voltage 943 845-009
BAT-ANT-RSMA-2AGN-R (10 pieces) 942 046-001
