REMOVING AND INSERTING THE OVEN
DOOR GLASS PANE
Oven door glass pane can be cleaned from the inside, but it has to be removed first.
Remove the oven door (see chapter "Removing and replacing the oven door").
1
Slightly lift the supports on the left and
right side of the door (marking 1 on the
support) and pull them away from the glass
pane (marking 2 on the support).
2
Hold the door glass pane by the lower
edge; slightly lift it so that it is no longer
attached to the support; and remove it.
3
To remove the third glass pane (only
with some models), lift and remove it.
Also remove the rubber seals on the glass
pane.
To replace the glass pane, observe the
reverse order. The markings (semi-circle) on
the door and the glass pane should overlap.
