4-22 Replacing parts
Hitachi Compute Rack 220H CRU Replacement Guide
Installing a PCI card
1. Perform reverse procedure of the removal to install a replacing PCI card.
• Make sure the PCI card is inserted straightly into the PCI slot
connector. When the PCI card is not in place, the PCI card may
not operate properly.
• The external connectors on the PCI card have to be parallel to
the bracket of the PCI slot. Adjust the position of the external
connectors properly when you secure the PCI card with screw.
When the gap between the external connector and bracket is not
appropriate, cables cannot be connected.
• Make sure the PCI riser is inserted straightly into the PCI riser
slot connector. When the PCI riser is not in place, the PCI card
may not operate properly.
• If a connector module is installed on the PCI card, remove the
connector before installing the PCI card into the PCI slot.
For information about the procedure for installing/removing the
connector module, see the document of the PCI card.
• Make sure that the two SAS cables and the cache backup cable
connects to the RAID card with cache backup module if any.
2. Perform the reverse procedure of removal to connect the SAS cable and the
cache backup cable to RAID card with cache backup module if any.
3. Install the rear top cover of the system.
See Installing the rear top cover on page 3-9.
4. Install the front top cover of the system.
See Installing the front top cover on page 3-10.
5. Reinstall the system to the rack cabinet.
See Sliding the system unit into a rack cabinet on page 3-6.
