24
Operating
Adjusting the focus
Adjusting the projector's elevator
The projector has Front foot for inclinations and Rear foot for horizontals. A spacer
is installed on the Rear elevator foot at the time of shipment, and the projector
is ready for use. If necessary, detach the spacer, and the elevator feet can be
manually twisted to make more precise adjustments.
Front foot Rear foot
0~2°
-1~1°
Front foot
Rear foot
Spacer
Spacer
Use the focus ring to focus the picture.
►Keep the spacer away from children and pets. Be careful not
to let them swallow the spacer. If swallowed consult a physician immediately for
emergency treatment.
WARNING
• The Front foot can be adjusted within 0~2°, while the Rear foot can
be adjusted within -1~1°.
•
After the foot is adjusted, it is possible to return it to the state of the shipment with a spacer.
It is recommended to keep the spacer and reuse it when relocating the projector.
NOTE
FOCUS ring
