Scalable storage capacity
■
The minimum conguration is a single rack with one controller chassis in a diskless
conguration.
■
A small system can be a single rack with one controller chassis and up to two drive
chassis or ash drive chassis.
■
A mid-sized system can be thr
ee racks with one controller chassis and a maximum of
eight combined LFF or SFF drive chassis and up to two ash module drive (FMD)
chassis.
■
For combined block and le stor
age systems, the maximum conguration depends
on how many HNAS servers and switches are installed. Consult your authorized
representative for examples of available congurations.
■
Maximum storage capacity:
●
The storage systems can be congured up to 65,280 logical volumes.
●
Congurable up to 2,304 SFF disk drives with a maximum physical disk capacity of
approximately of 3.9 PB per storage system, or up to 1,152 LFF disk drives with a
maximum physical disk capacity of approximately 6.8 PB per storage system.
●
A drive intermix conguration can be congured up to 576 ash module drives
with a maximum physical capacity of 8.0 PB per storage system.
Flexible connectivity
The storage system supports connectivity to mainframe hosts through FICON
®
front-end
directors and to open servers via Fibre Channel, iSCSI, and Fibre Channel over Ethernet
(FCoE) front-end directors. The storage system can be congured with a combination of
all of these front-end directors to support both mainframe hosts and open servers
simultaneously.
For details about host connectivity and OS support, see
https://support.hds.com/en_us/
interoperability.html.
Flexible connectivity
Chapter 1: VSP G1000, VSP G1500, and VSP F1500 overview
Hitachi Virtual Storage Platform G1000, G1500, and VSP F1500 Hardware Guide 17

Hitachi G1500 Specifications

General

Category	Storage
Type	Modular Storage System
Model	G1500
Drive Types Supported	SAS, SSD
Host Interfaces	Fibre Channel, iSCSI, FCoE
RAID Levels Supported	0, 1, 5, 6, 10
Management Software	Hitachi Command Suite
