3 - 2
NOTE: If the monitor display screen does not appear on the
LCD within 3 minutes after turning on the power, or if
an error message appears on the LCD, refer to “4.6
Troubleshooting” or “4.7 Error Messages”.
1) Turn on the power switch of the detector.
2) Liquid Crystal Display (LCD) presents the initial screen,
which changes to the initializing screen after a few seconds.
At the same time, a test for self-diagnosis (initialization) is
carried out.
* The current channel setting LED and the Xe LAMP LED
will light in blue.
<Initial screen>
The sequence of wavelength drive (check of reference point
for drive), lighting of the lamp and auto zeroing is performed.
3) The first monitor screen will be indicated after initialize-
processing is completed normally.
Press △ ▽ key to indicate the second and the third
monitor screen.
Press △ ▽ ESC key to return to the first monitor
screen.
* An error message will be presented if an abnormality
occurs during initializing. Check Section 4.6.
