(1) Full Scale Range of Recorder
(a) Press the RECORD key.
(b) The recorder setting screen appears.
<Recorder setting screen>
RECORD (RCD RANGE=1, RCD SPEED=2,
1 SPECT RCD=3)
Press numeric key 1 and then the ENT key to select
RCD RANGE (recorder range).
(c) The recorder full scale range setting screen appears.
<Recorder full scale range setting screen>
RCD RANGE (1 - 1000)
1000
Press numeric keys 1 to 1 0 0 0 and then the ENT
key to set a recorder full scale range.
* Initial (default) value: 1000
(d) When the setting of recorder full scale range is finished,
the system returns to the 1
st
monitor screen.
(2) Setting of Recorder Output Speed
(a) Press the RECORD key.
(b) The recorder setting screen appears.
<Recorder setting screen>
RECORD (RCD RANGE=1, RCD SPEED=2,
2 SPECT RCD=3)
Press numeric key 2 and then the ENT key to select
RCD SPEED (recorder speed).
To Next Page
