3 - 44
<Background spectrum No. setting screen>
BACKGROUND SPECTRUM NO. (0 ~ 4)
0
Press a numeric key 0 to 4 and then the ENT key to
select whether or not to correct the output spectrum.
* 0 : Spectrum selected at RECORD
SPECTRUM NO. will be output as it is.
1 - 4 : Spectral data obtained by subtracting the
specified background data from the
spectrum selected at RECORD
SPECTRUM NO. will be output.
* Initial (default) value: 0
* When the energy spectrum and spectrum type are
mismatched, the error message indicated below will
appear. Press the CL key and the 1st monitor
screen will return.
<Error display>
SPECTRA ARE MISMATCHED
PRESS “CL” KEY TO CLEAR MESSAGE
(e) The “ready for output” monitor screen will appear.
<“Ready for output” monitor screen>
RCD NO. SPEED WL-RANGE (Em) WIDTH:STD
1 60 200-600 PRESS “START”
Press the START key.
* Pressing the ESC key prior to the START key will
cancel the process.
* The output spectrum No. set before will be indicated
at RCD NO.
(f) The output monitor screen appears, and a spectrum is
output.
<Output monitor screen (spectrum output under way)>
RCD NO. Ex Em FL SPEED MODE
1 250 350 0.0 60 Em
* Pressing the STOP key during spectrum output will
cancel the process.
To Next Page
