Hitachi RAW-35RHC - Indoor Unit Electrical Components

4 Electrical checks of main parts
Indoor unit
SMGB0135 rev.0 - 06/2020
48
4.2 Indoor unit
4.2.1 Safety thermostat (water temperature safety device)
20A 250V
L
N
N
L
46,5±1
27,50
Ø4
Ø2,5
12,50
6,
8
30
55±1
6.30x0.8 EN60730
15,4±0,3
2.7
1075±20
70±5
Ø
Max. 20
V
D E
6±0.5
A1 A2
B1 B2
Reset button
Threaded cap
NUT-S-1607/00
ELECTRIC DIAGRAM NC
Disconnection
temperature
90+/-5ºC
Rated current 20 A
RESET button The appliance can not connect again until the bulb doesn’t fall 50ºC at least
