S1 series standard inverter
-29-
Contact capacity: 3A / AC250V, 1A / DC30V
RO2 relay output; RO2A is NO, RO2B is NC, RO2C is common port
Contact capacity: 3A / AC250V, 1A / DC30V
1. Switch capacity: 50mA / 30V
2. Range of output frequency: 0–50kHz
3. Duty ratio: 50%
Common port of open collector output
1. Switch capacity: 50mA / 30V
2. Range of output frequency: 0–1kHz
485 communication interface
Provide input digital working power from external to internal
Voltage range: 12–24V
The inverter provides user power; the maximum output current is 200mA
1. Internal impedance: 3.3kΩ
2. Accept 12–30V voltage input
3. This terminal is bi-directional input terminal and supports NPN
/ PNP connection modes
4. Max. Input frequency: 1kHz
5. All are programmable digital input terminals, users can set the
terminal function via function codes
Besides S1–S4 functions, it can also act as high frequency pulse input channel
Max. Input frequency: 50kHz
Duty ratio: 30% –70%
1. Safe torque off (STO) redundant input, connect to external NC
contact, STO acts when the contact opens, and the inverter
stops output
2. Safety input signal wires use shielded wire whose length is
within 25m
4.4.2 Input/output signal connection diagram
Set NPN /PNP mode and internal/external power via U-type short-contact tag. PNP internal mode is
adopted by default.
