Hitachi SJ200 Series

Analog Input Operation
Operations
and Monitoring
4–52
The following table shows the available analog input settings. Parameter A005 and the
input terminal [AT] determine the External Frequency Command input terminals that are
available, and how they function. The analog inputs [O] and [OI] use terminal [L] as the
reference (signal return).
Other Analog Input-related topics:
• “
Analog Input Settings” on page 3–13
• “Additional Analog Input Settings” on page 3–27
• “Analog Signal Calibration Settings” on page 3–51
• “Analog Input Current/Voltage Select” on page 4–23
• “ADD Frequency Enable” on page 4–32
• “Analog Input Disconnect Detect” on page 4–44
A005 [AT] Input Analog Input Configuration
00
OFF [O]
ON [OI]
01 (ignored) Sum ([O] + [OI])
02
OFF [O]
ON Keypad potentiometer
03
OFF [OI]
ON Keypad potentiometer
