CE–EMC Installation Guidelines
Appendix D
D–4
SJ200 inverter designed for use in Europe (–xxxLFEF/xxxHFEF models) have built-in
line filters. In the event your application needs additional filtering, the following
diagrams show control panel mounting and wiring examples for different filter types.
L1 L2L3 PE M
3~
SJ200 inverter with footprint-type filter
To Next Page
