Hitachi SJ200 Series

SJ200 Inverter
Appendix B
B–19
ModBus Data Listing
ModBus Coil List
The following tables list the primary coils for the inverter interface to the network. The
table legend is given below.
• Coil Number - The network address to the coil, which is a single bit (binary) value
• Name - The functional name of the coil
• R/W - The read-only (R) or read-write (R/W) access permitted to the inverter data
• Description - The meaning of each of the states of the coils
List of Coil Numbers
Coil
Number
Name R/W Description
0000h (Reserved) R —
0001h Run command R/W 0.....Stop
1.....Run (enabled when A003=03)
0002h FW/REV command R/W 0.....REV
1.....FW (enabled when A003=03)
0003h External trip (EXT) R/W 0.....No trip event
1.....Trip occurred
0004h Trip reset (RS) R/W 0.....No reset condition
1.....Reset
0005h (Reserved) R —
0006h (Reserved) R —
0007h Intelligent input terminal 1 R/W 0.....OFF *1
1.....ON
0008h Intelligent input terminal 2 R/W
0009h Intelligent input terminal 3 R/W
000Ah Intelligent input terminal 4 R/W
000Bh Intelligent input terminal 5 R/W
000Ch Intelligent input terminal 6 R/W
000Dh (Not used) — —
000Eh Run/Stop status R 0.....Stop (corresponds to D003 monitor)
1.....Run
000Fh FW/REV status R 0.....FW
1.....RV
0010h Inverter ready R 0.....Not ready
1.....Ready
0011h (Reserved) R —
0012h (Reserved) R —
0013h (Reserved) R —
