ModBus Data Listing
Appendix B
B–20
Note 1: ON usually when either the control circuit terminal board or a coil is ON.
Among intelligent input terminals, the control circuit terminal board is a high-
priority terminal. If the master cannot reset the coil ON status due to a trans-
mission line break, turn ON and OFF the control circuit terminal board to
make the coil OFF status.
Note 2: The content of a transmission error is held until the error is reset. (The error
can be reset while the inverter is running.)
0014h Alarm signal R 0.....Normal
1.....Trip
0015h PID deviation signal R 0.....OFF
1.....ON
0016h Overload signal R
0017h Frequency arrival signal
(set frequency or above)
R
0018h Frequency arrival signal
(at constant speed)
R
0019h Run Mode signal R
001Ah Data writing R 0.....Normal status
1.....Writing
001Bh CRC error R 0.....No error *2
1.....Error
001Ch Overrun error R
001Dh Framing error R
001Eh Parity error R
001Fh Check sum error R
List of Coil Numbers
Coil
Number
Name R/W Description
