ModBus Data Listing
Appendix B
B–22
D001 Output frequency
monitor
R Real-time display of output
frequency to motor, from
0.0 to 400.0 Hz
00Ah 0 to
4000
0.1 Hz
D002 Output current monitor
*1
R Filtered display of output
current to motor (100 ms
internal filter time constant),
range is 0 to 200% of inverter
rated current
00Bh 0 to
2000
0.1%
D003 Rotation direction
monitor
R Three different indications:
00...Stop
01...Forward
02...Reverse
00Ch 0, 1, 2 —
D004
(high)
Process variable (PV),
PID feedback monitor
R Displays the scaled PID
process variable (feedback)
value (A075 is scale factor),
range is 0.00 to 99900
00Dh 0 to
999900
0.00%
times
const.
D004
(low)
R 00Eh
D005 Intelligent input
terminal status
R Displays the state of the intelli-
gent input terminals [x],
Bit 0 = [1] to Bit 7 = [6]
00Fh 0 to 63 —
D006 Intelligent output
terminal status
R Displays the state of the intelli-
gent output terminals [x],
Bit 0 = [11], Bit 1 = [12],
Bit 2 = [AL]
0010h 0 to 7 —
D007
(high)
Scaled output frequency
monitor
R Displays the output frequency
scaled by the constant in B086.
Decimal point indicates range:
0.00 to 99999
0011h 0 to
999999
0.01 Hz
times
const.
D007
(low)
R 0012h
D013 Output voltage monitor R Voltage of output to motor,
range is 0.00 to 200.00%
0013h 0 to
20000
0.01%
D016
(high)
Cumulative operation
RUN time monitor
R Displays total time the inverter
has been in RUN mode in
hours.
Range is 0 to 999000
0014h 0 to
999999
1 hour
D016
(low)
R 0015h
D017
(high)
Cumulative power-on
time monitor
R Displays total time the inverter
has been in RUN mode in
hours.
Range is 0 to 999000
0016h 0 to
999999
1 hour
D017
(low)
R 0017h
D080 Trip counter R Number of trip events,
range is 0 to 65535
0018h 0 to
65535
1 trip
event
D081 Trip monitor 1 R Displays trip data 0019h — —
D082 Trip monitor 2 R Displays trip data 001Ah — —
D083 Trip monitor 3 R Displays trip data 001Bh — —
List of Holding Registers
Func.
Code
Name R/W Description
Network Data
Reg. Range Res.
To Next Page
