SJ200 Inverter
Appendix B
B–23
Note 1: Assume that the inverter current rating is 1000 (for D002).
The following table lists holding registers for the “D” Group Monitor Functions.
Note 1: Stores new data made by transmission (for Write all memory). For more
information, refer to the Store New Register Data (ENTER command).
Holding Registers, “D” Group Monitor Functions
Func.
Code
Name R/W Description
Network Data
Reg. Res.
D081 Trip monitor 1
R Trip monitor 1: factor code 0100h —
R Frequency 0101h 0.1 Hz
R Current 0102h 0.1 %
R Voltage 0103h 0.1 V
R Run time (high) 0104h 1. h
R Run time (low) 0105h
R ON time (high) 0106h 1. h
R ON time (low) 0107h
D082 Trip monitor 2
R Trip monitor 1: factor code 0108h —
R Frequency 0109h 0.1 Hz
R Current 010Ah 0.1 %
R Voltage 010Bh 0.1 V
R Run time (high) 010Ch 1. h
R Run time (low) 010Dh
R ON time (high) 010Eh 1. h
R ON time (low) 010Fh
D083 Trip monitor 3
R Trip monitor 1: factor code 0110h —
R Frequency 0111h 0.1 Hz
R Current 0112h 0.1 %
R Voltage 0113h 0.1 V
R Run time (high) 0114h 1. h
R Run time (low) 0115h
R ON time (high) 0116h 1. h
R ON time (low) 0117h
— Write all memory W Infinite *1 0900h —
