Hitachi SJ200 Series User Manual

SJ200 Inverter
Getting Started
1–5
SJ200 Inverter Specifications
Model-specific tables for 200V and 400V class inverters
The following tables are specific to SJ200 inverters for the 200V and 400V class model
groups. Note that “
General Specifications” on page 1–10 apply to both voltage class
groups. Footnotes for all specifications tables follow the table below.
Item 200V Class Specifications
SJ200 inverters,
200V models
EU version 002NFEF 004NFEF 005NFEF 007NFEF 011NFEF
USA version 002NFU 004NFU — 007NFU —
Applicable motor size *2 kW 0.2 0.4 0.55 0.75 1.1
HP 1/4 1/2 3/4 1 1.5
Rated capacity
(kVA)
230V 0.6 1.0 1.1 1.5 1.9
240V 0.6 1.0 1.2 1.6 2.0
Rated input voltage 1-phase: 200 to 240V ±10%, 50/60 Hz ±5%,
3-phase: 200 to 240V ±10%, 50/60 Hz ±5%,
(037LFU, 055LFU, and 075LFU 3-phase only)
Integrated EMC
filter
EU version Single phase filter, Category C3 *5
USA version —
Rated input
current (A)
1-phase 3.5 5.8 6.7 9.0 11.2
3-phase 2.0 3.4 3.9 5.2 6.5
Rated output voltage *3 3-phase: 200 to 240V (proportional to input voltage)
Rated output current (A) 1.6 2.6 3.0 4.0 5.0
Starting torque *7 200% or more
Dynamic braking
approx. %
torque, short
time stop *8
without resistor,
from 50 / 60 Hz
100%: ≤ 50Hz
50%: ≤ 60Hz
with resistor 150%
DC braking Variable operating frequency, time, and braking force
Weight
EU version
(-NFEF
kg 0.8 0.95 0.95 1.4 1.4
lb 1.75 2.09 2.09 3.09 3.09
US version
(-NFU)
kg 0.7 0.85 — 1.8 —
lb 1.54 1.87 — 3.97 —

Hitachi SJ200 Series Specifications

General

Series	SJ200
Category	Inverter
Output Frequency	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds
Cooling Method	Fan cooled
Humidity	5 to 95% RH (non-condensing)
Control Method	V/f Control, Sensorless Vector Control
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Ambient Temperature	-10 to 50°C
Braking Unit	Built-in
Communication	RS-485 (Modbus RTU)
Altitude	Up to 1000m
Output Voltage	3-Phase 200-240 VAC, 3-Phase 380-480 VAC
Storage Temperature	-20 to +60°C (-4 to 140°F)
