12
(4) Message format for Write Single Register (Function code: 0x06)
● Write a content in the Holding Register to reflect it in the IJ Printer.
● The number of bytes that can be written in the Holding Register per time is fixed to 2 bytes.
Request message configuration
No. Name Size Range Description
1 Device address 1 byte 0x01 to 0x03 Sets device address.
2 Function code 1 byte 0x06
Sets function code (Write Single
Register).
3 Writing address 2 bytes
0x0000 to
0xFFFF
Sets writing address. Address is set
in word units.
4 Data to be written 2 bytes
0x0000 to
0xFFFF
Sets data to be written.
Response message data configuration (normal)
No. Name Size Range Description
1 Device address 1 byte 0x01 to 0x03 Sets device address received as it is.
2 Function code 1 byte 0x06 Sets function code received as it is.
3 Writing address 2 bytes
0x0000 to
0xFFFF
Sets writing address received as it is.
4 Data to be written 2 bytes
0x0000 to
0xFFFF
Sets data to be written received as it
is.
Response message data configuration (abnormal)
No. Name Size Range Description
1 Device address 1 byte 0x01 to 0x03 Sets device address received as it is.
2 Function code 1 byte 0x86 Adds 0x80 to function code received.
3 Error code 1 byte 0x01 to 0x03
Sets error code. Error code differs
according to cause.
