4.5 Detail of Data configuration
(1) Details of Analysis information
When an error occurs in the external communication being conducted, the error cause can be
obtained from the analysis information of IJ printer status available at Input Registers.
Analysis information 1 (Function Code): Functional code of the communication message
which resulted in error.
Analysis information 2 (Classification code): Functional classification of the communication
message which resulted in error.
Analysis information 3 (Error factor): Cause which resulted in error.
Analysis information 4 (Preparation for future): Reserved area for future use. 0x0000 fixed.
Code table of Analysis information
No. item code Content
1
Analysis information 1
(Function code)
0x0010 Write on Holding Register
0x0006 Write one word on Holding Register
0x0003 Read Holding Register
0x0004 Read Input Register
Other than
the above
Function code which is NOT available
2
Analysis information 2
(Classification code)
0x0000 No classification assigned
0x0001 Index
0x0002 Print description
0x0003 Delete of Print contents
0x0004 Print data Recall
0x0005 Print data Register
0x0006 Print format
0x0007 Print specification
0x0008 Calendar conditions
0x0009 Substitution rules.
0x000A Time count
0x000B Shift code
0x000C Count conditions
0x000D Various print setup
0x000E Online/Offline
0x000F Remote operation
0x0010 Time control
0x0011 User environment setup (Preparation for future)
0x0012 Touch screen setup
0x0014 Operation management
0x0015 Circulation control
0x0016 Print data management
0x0017 Group control
0x0018 Editing Substitution rules
0x001A Print job control (Preparation for future)
0x001B User pattern (Fixed size)
0x001C User pattern (Free size)
3
Analysis information 3
(Error factor)
0x0001 Invalid Function code
0x0002 Invalid Address
0x0003 Invalid Data size
0x0004 Invalid CRC code
0x0005 Invalid Offline
0x0006 Invalid Message repeat print
0x0007 Communication is NOT allowed when Ink ejection is stopped.
0x0010 Invalid data
4
Analysis information 4
(Preparation for future)
0x0000 0x0000 fixed.
