Number Item Description
4 PATH (OUT side) Green: Indicates that the
OUT side is linked up.
5 POWER Green: Indicates that the
power is supplied to the
ENC.
6 LOCATE Amber: A LED to specify the
chassis location on the rear
of the chassis.
The LED can be lit/turned
o by Maintenance Utility.
7 ALARM (REPLACE) Red: Lights up when
replacement of the ENC is
possible.
8 Consol port Not in use
Number Item Description
1 RDY2 Green: Normal operation
O: Erroneous operation or
out of operation
2 RDY1 Green: Normal operation
O: Erroneous operation or
out of operation
Drive box
Chapter 2: Hardware overview
Hitachi Virtual Storage Platform 5000 Series Hardware Guide 30
