CDA3-35 User’s Guide
Take the following steps to manually set up your computer’s IP address to connect to
the CDA3-35:
NOTE: This example uses Windows XP; the procedure for your operating system
may be different.
1 Click Start, then click Control Panel.
2 In the window that displays, double-click Network Connections.
3 Right-click your network connection (usually Local Area Connection) and click
Properties.
4 In the General tab’s This connection uses the following items list, scroll
down and select Internet Protocol (TCP/IP). Click Properties.
5 You can get an IP address automatically, or specify one manually:
If your CDA3-35’s DHCP server is active, select Get an IP address
automatically.
If your CDA3-35’s DHCP server is active, select Use the following IP
address. In the IP address field, enter a value between 192.168.100.2 and
192.168.100.254 (default). In the Subnet mask field, enter 255.255.255.0
(default).
NOTE: If your CDA3-35 is not using the default IP address, enter an IP address and
subnet mask that places your computer in the same subnet as the CDA3-35.
6 Click OK. The Internet Protocol (TCP/IP) window closes. In the Local Area
Connection Properties window, click OK.
Your computer now obtains an IP address from the CDA3-35, or uses the IP address
that you specified, and can communicate with the CDA3-35.
1.5 GUI Overview
This section describes the CDA3-35’s GUI.
Take the following steps to see the CDA3-35’s GUI.
