CDA3-35 User’s Guide
Figure 13: The Status: Spectrum Screen (Constellation)
The following table describes the labels in this screen.
Table 13: The Status: Spectrum Screen (Constellation)
Receiver Information This displays the information of the current receiver
frequency.
Frequency This displays the frequency of the measurement.
Modulation
This displays the modulation of the measurement.
Bandwidth This displays the bandwidth information.
Power This displays the power level of the spectrum.
MER This displays the modulation error ratio.
Quadrature x In-phrase This displays the spectrum constellation.
Stop Click this to stop the scanning.
