HITRON CVE-30360 USER’S GUIDE
INTRODUCTION
1.3 LEDS
This section describes the CVE-30360’s LEDs (lights).
LAN1 Use these ports to connect your computers and other
network devices, using Category 5 or 6 Ethernet cables
with RJ45 connectors.
LAN2
LAN3
LAN4
LINE 1 Use these ports to connect your analog phones for VoIP
services, using cables with RJ11 connectors.
LINE 2
CABLE Use this to connect to the Internet via an F-type RF
cable.
POWER Use this to connect to the 12v/2A power adapter that
came with your CVE-30360.
NEVER use another power adapter with
your CVE-30360. Doing so could harm
your CVE-30360.
ON/OFF Use this button to turn your CVE-30360 on or off.
To turn the CVE-30360 on, press and hold the ON/
OFF button for less than 1 second.
To turn the CVE-30360 off, press and hold the ON/
OFF button for 1~2 seconds.
TABLE 1: Hardware Connections
