Hitron CVE-30360 User Manual

35
HITRON CVE-30360 USER’S GUIDE
CABLE
Frequency to Tune to This displays the current center frequency in Hertz (Hz)
over which data is transmitted to the CVE-30360 over
the CATV interface. This is the frequency to which the
CVE-30360 is locked in; it will only scan for another
frequency if this frequency becomes unavailable.
If you want the CVE-30360 to attempt to connect at a
different frequency, enter it in the field and click Apply.
NOTE: Do not change the frequency unless you have a
good reason to do so.
Scanning Start
Frequency
This displays the frequency in Hertz (Hz) at which the
CVE-30360 begins scanning for a connection over the
CATV interface (if a frequency is not already locked in).
Channel Frequency This displays the actual frequency of each downstream
data channel to which the CVE-30360 is connected.
Modulation This displays the type of modulation that each
downstream channel uses. Possible modulation types
Signal Strength This displays the power of the signal of each
downstream data channel to which the CVE-30360 is
connected, in dBmV (decibels above/below 1 millivolt).
Signal Noise Ratio This displays the Signal to Noise Ratio (SNR) of each
downstream data channel to which the CVE-30360 is
connected, in dB (decibels).
Upstream
NOTE: The upstream signal is the signal transmitted from the CVE-30360.
Channel ID This displays the ID number of each channel on which
the upstream signal is transmitted.
Upstream Frequency This displays the frequency in Herz (Hz) of each
upstream data channel to which the CVE-30360 is
connected.
Upstream Bandwidth This displays the bandwidth of each upstream data
channel to which the CVE-30360 is connected (in Hertz).
SCDMA Mode This displays the Synchronous Code Division Multiple
Access (SCDMA) mode of each channel on which the
upstream signal is transmitted.
Transmission Signal
Strength
This displays the transmitted power of the signal of each
upstream data channel to which the CVE-30360 is
connected, in dBmV (decibels above/below 1 millivolt).
Cable Modem IP Information
IP Address This displays the CVE-30360’s WAN IP address. This IP
address is automatically assigned to the CVE-30360
Subnet Mask This displays the CVE-30360’s WAN subnet mask.
TABLE 8: The Cable > Status Screen (continued)
