HITRON CVE-30360 USER’S GUIDE
FIREWALL
Port Range These fields display the ports to which the rule applies:
The Public field displays the incoming port range.
These are the ports on which the CVE-30360
received traffic from the originating host on the WAN.
The Private field displays the port range to which the
CVE-30360 forwards traffic to the device on the LAN.
Protocol This field displays the protocol or protocols to which this
rule applies:
Transmission Control Protocol (TCP)
User Datagram Protocol (UDP)
Transmission Control Protocol and User Datagram
Protocol (TCP/UDP)
Generic Routing Encapsulation (GRE)
Encapsulating Security Protocol (ESP)
IP Address This displays the IP address of the computer on the LAN
to which traffic conforming to the Public Port Range
and Protocol conditions is forwarded.
Enable Use this field to turn each port forwarding rule on or off.
Select this checkbox to enable the port forwarding
rule.
Deselect this checkbox to disable the port forwarding
rule.
Add New Click this to define a new port forwarding rule. See
Adding or Editing a Port Forwarding Rule on page 58 for
information on the screen that displays.
Edit Select a port forwarding rule’s radio button ( ) and
click this to make changes to the rule. See Adding or
Editing a Port Forwarding Rule on page 58 for
information on the screen that displays.
Delete Select a port forwarding rule’s radio button ( ) and
click this to remove the rule. The deleted rule’s
information cannot be retrieved.
Apply Click this to save your changes to the fields in this
screen.
Cancel Click this to return the fields in this screen to their last-
saved values without saving your changes.
Help Click this to see information about the fields in this
screen.
TABLE 18: The Firewall > Forwarding Screen (continued)
