Hobart Handler 125 EZ - Volt-Ampere Curves

OM-923 Page 12
3-3. Volt-Ampere Curves
The volt-ampere curves show the
minimum and maximum voltage
and amperage output capabilities of
the welding power source. Curves
of other settings fall between the
curves shown.
ssb1.1 10/91 − 210 519-A
8.0
13.0
18.0
23.0
28.0
33.0
0.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 100. 0 110.0 120.0 130.0
Range 1
Range 2
Range 3
Range 4
Amperage
Voltage
(18-16 ga)
(16-12 ga)
(12-10 ga)
(10ga-3/16”)
