Hobart Handler 125 EZ - Section 5: Operation; Control Panel Overview

OM-923 Page 18
SECTION 5 − OPERATION
5-1. Controls
1 Material Thickness Selector
Switch
Use switch to select the material
thickness range. Do not switch
under load.
. Switch must “click” into detent
position for weld output.
2 Power Switch
Ref. 230 001-A
1
2
