OM-923 Page 22
6-5. Replacing Gun Contact Tip
Tools Needed:
Ref. 804 241-A
! Turn Off power before replacing
contact tip.
1 Nozzle
Remove nozzle.
2 Contact Tip
3 Tip Adapter
Cut off welding wire at contact tip.
Remove contact tip from tip adapter,
and install new contact tip. Reinstall
nozzle.
1
2
3
