9. Gas system
107
9.3 External gas socket *
Theexternalsocketforgasisusedtoconnectexternalgasdevices
suchasagasbarbecueorlamp.
The plug connection can only be hitched when the emergency
shutovalvehasbeenclosed.Pushbacktheclutchsleevetoundo
thesafetylatch.
The coupling valve has been constructed in such a way that the
emergencyshutovalvecanonlybeopenedifagashosehasbeen
attached. When hitching, the plug connection is plugged into the
safetycoupling.
Ifnogashosehasbeenattached,alwaysusetheprotectivecapto
shuttheopeningofthevalve.
Theoperatingpressureofdevicestobeconnected
mustbe30mbar.
Maximumperformanceofdevicestobeconnected:
1.5kW.
Theexternalsocketforgasisonlysuitableforextrac-
tinggas,notforsupplyinggastothesystem.
External gas socket
