7. Installation of electrical devices
7.4 Electrical supply
Electricityforthecaravancanbeobtainedfromthefollowing
connections:
- 230Vmainsconnection50Hz
- viathebasevehicleifitisconnectedusingthe13-poleplug
(limitedfunctions)
- via a built-in auxiliary battery *.Everythingthatuses12V,such
aslighting,watersupply,etc.,isavailable.
Supply via mains connection
Thecaravanreceivesitselectricpowersupplyviathe230VCEE
feederplugonthesidewallofthevehicle.
CEE external socket
To disconnect the electric connection
• Switchotheautomaticcircuitbreaker
l
bypressingthe
rockerbuttondown
m
.
• RemovetheCEEconnectorplug
k
.
• Pressthecoverap
j
downuntilitclicksintoplace.
Automatic circuit breaker with FI ('fast interrupt')
switch
OnlyplugsandcordsthatcomplywithCEEstan-
dardsmaybeused.
To set up an electric connection
• Pulloutthe13-poleplugthatconnectstothebasevehicle.
• Switchotheautomaticcircuitbreaker
l
bypressingthe
rockerbuttondown
m
.
• TakeholdofthebottomofthecoverapoftheCEEexternal
socket
j
andpullitup.
• Completelyunwindtheconnectorcable.
• OpenthecapoftheCEEconnectorplugbypullingitupina
90°angle.
• Inserttheplug
k
untilitlocksintoplace.
• Switchtheautomaticcircuitbreaker
l
backon.
Connected 230V feeder plug
1
2
4
3
Alwaysrstunhookthetrailerfromthecarbefore
settingupthe230Vmainsconnection.
