5. Exterior structure
39
Pleated screen and insect screen
Pull the plissé and the insect screen on the entry door
to the desired position. To open, carefully guide the rail
back to the original position in order to fold the plissés
correctly.
The insect screen may only be pulled out if the door or
at least the upper part of the door is open. The insect
screen for the partitioned door can only be opened until
a slight resistance is felt at the level of the lower part
of the door.
Only shut the door after the insect screen has been
pushed back into its original position!
Partitioned (two-part) entrance door
1
2
One-piece entrance door
1
2
jGuiding rail for pleated screen
kGuiding rail for insect screen
jGuiding rail for pleated screen
kGuiding rail for insect screen
To open
• Unlatch the lock with the key.
• Hold the locking knob between your thumb and index nger
and press rmly.
• Open the ap downward.
To close
• Close the ap upward.
• Press the ap on the upper left and right-hand corners to ensu-
re that all of the locks actually click into place.
• Latch the lock with the key.
Service ap
Service ap
