3. Chassis
a) liquid gas supply
390 SF
400 - 495
UL/UFE
470
KMF
495
WFB
540 - 720 WLU,
660 WFU
720 KFU,
545 KMF
560 WFU
660 WFC
770
CFf, CL
Number of built-in gas regulators: (kg)
1 1 1 1 1 1 1 1
weight of an aluminium gas bottle: (kg)
5,5 5,5 5,5 5,5 5,5 5,5 5,5 5,5
weight of an 11 kg gas lling: (kg)
11 11 11 11 11 11 11 11
Total: (kg)
16,5 16,5 16,5 16,5 16,5 16,5 16,5 16,5
b) uids
25 l xed fresh water tank: (kg)
25 25 25 25 --- --- --- ---
50 l xed fresh water tank: (kg)
--- --- --- --- 50 50 50 50
Toilet ushing C 500: (kg)
--- 15 --- --- 15 --- --- ---
Toilet ushing C 402: (kg)
15 --- --- --- --- --- --- ---
Toilet ushing C 200 S: (kg)
*
--- ---
* *
---
* *
---
Toilet ushing C 263 S: (kg)
*
--- --- --- --- --- --- ---
*
S-heating (therme)
5 5 5 --- 5 5 --- 5
Combi heating system (boiler)
--- ---
--- 10 --- --- 10 ---
Total: (kg)
45 45 30 35 70 55 60 55
Total basic equipment: (kg)
61,5 61,5 46,5 51,5 86,5 71,5 76,5 71,5
3. Additional equipment / optional extras
Mass of the equipment that was assembled by the manufacturer in or
on the camper in addition to the standard equipment. These optional
extras will be shown in the actual mass of the vehicle if
− they are not part of the standard scope of equipment,
− Hobby was responsible for assembling them,
− the customer can order them.
4. Actual mass
Sum of the mass when ready to drive and the optional extras or
additional equipment assembled by the manufacturer.
5. Loading capacity / additional load
Dierence between the technically permissible maximum weight
and the actual mass of the vehicle.
6. Minimum loading capacity
The loading capacity must be equal at least to the formula:
10 x (n + L), whereby:
n = highest number of sleeping spaces
L = total length of the superstructure
The minimum loading capacity includes objects that users may carry
in the camper which are not included in the mass when ready to drive
or in the optional extras (e.g. clothing, toilet and kitchen ttings, food,
camping equipment, toys, pets).
The remaining additional load (5.) must always be greater than or
equal to the minimum loading capacity (6.); this must be taken into
account when determining the conguration of the vehicle.
*Toilet without separate water tank for ushing
