7. Installation of electrical devices
DOMETIC* air-conditioning system
Thesettypeofoperation,fanlevelanddesiredroomtemperature
aredisplayedinthemenufortheDometicair-conditioningsystem.
Thelowermenuiconisshowningreenwhentheair-conditioning
systemisinoperation.
Nexttothisicon,thevalue
ON=on(greenicon)or
OFF=air-conditioningsystemisnotinoperation(whiteicon)isshown.
Thetypeofoperationcanbechangedusingthe“+/-”softkeyson
menubarCorbyturningthecontrolknob.Thenewtypeofopera-
tionmustbeconrmedbypressingthecontrolknoborbymeans
ofthe“On/O”softkey.
Submenu: Selecting the type of operation
