Hobby optima - 230 V System Fuse Protection

Electrical Installations
07-20
OnlyplugsandcordsthatcomplywithCEEstandards
may be used.
To disconnect the electric connection:
• Switchotheautomaticcircuitbreaker
j
bypressingthe
rockerswitchdown
k
.
• Pressthelever
n
intheexternalsocketdown.
•RemovetheCEEplug
m
.
• Pressthecoverap
k
(p.07-19)oftheexternalsocket
downuntilitclicksintoplace.
The230Vsystemisprotectedbyatwo-pole13Aautomatic
circuitbreaker
j
, which is located either by the refrigerator,
theclothescupboardorthesteptothebed.(Exceptionsto
thisincludespecialinstallations,suchashot-waterheating,
etc..Inthiscase,anadditionaltwo-pole16Acircuitbreakerhas
beeninstalled.)Iftherearetwoautomaticcircuitbreakers,both
must be switched on.
Fuse protection for the 230V system
1
2
