Electrical Installations07-21
Rules for the mains connection
•
Useonlya3x2.5mm
2
cable with a maximum length of 25 m,
aCEEplugandconnectortoconnectthemotorhometoan
external 230 V mains.
• Afterthemainsconnectionhasbeenpluggedin,boththe
modular and the vehicle battery will automatically be char-
gedbythebatterychargerinthemotorhome(evenifthe
ControlPanelhasnotbeenswitchedon).
Whenobtainingelectricityviaacabledrum,thismust be
completelyunwound,asotherwiseinductionmaycause
thecabletoheatup,whichcouldleadtoburning.
(Providedthereisnoprotectionagainstoverheating)
• The 230 V mains connection in the motor home has been
designedforatotalpowerconsumptionof3000W.Ifaddi-
tional devices requiring electricity are connected, such as a
waterheater,etc.,youmustensurethatthiselectricpower
valueisnotexceeded,takingotherelectricalequipmentin
use, such as the refrigerator, heating, etc., into account.
Repairsmustnotbecarriedoutontheresidualcurrent
device.
Aresidualcurrentdevicedoesnotguaranteeanyprotec-
tionagainstthedangerfromanelectricshock.Itdoes
notprotectagainstpossibleelectricalaccidents.
1
2
Residual current device
Thestandardversionofyourvehicleisequippedwitha
residualcurrentdevicethatwillinterrupttheelectriccircuitin
caseofapossibleresidualcurrent.Shouldtherebeamal-
function,thepassengercircuitbreakeropenstheentire
230 V circuit.
