Electrical Installations
07-26
Charger CA-360, 25 A power charging module
Thechargersuppliesthebatterieswithelectricpowerwhen
thereisbus-poweredmainsoperation.
Astheyheatup,thechargerreducesitspoweroutputto
ensure that there is no chance of overheating.
Thechargingdevicecanbeaccessedfromthebackof
thepassengerseat.
j
Socket;themiddlepinisthesensor.
k
PCBswitches.Theswitchesmustallbeinthetopposi-
 tion,i.e.allsetto“o”.
l
Changeovercontact,forfreedisposal.
m
Contactbridge,fanon/o.
n
LEDblinkstoshowcurrentchargingmode.
1 2 3 4 5
