5. TECHNICAL DATA
Swing Over Bed 210mm
Swing OVer Cross Slide 110mm
Distance Between Centers 400mm
Width of Bed 100mm
Hole Through Spindle 21mm
Taper in Spindle Nose MT3
Number of Spindle Speeds Variable
Range of Spindle Speeds 50-2500RPM
Number of Metrich Threads 10
Range of Metrich Thread 0-5~3.0mm
Number of Imperial Threads 8
Range of Imperial Thread 8~44 T.P.I.
Range of Longitudinal Feed 0.1~0.2mm
Tool Post Type 4-Way
Maximum Compound Slide Travel 85mm
Maximum Cross Slide Travel 80mm
Maximum Carriage Travel 290mm
Tailstock Spindle Travel 55mm
Taper in Tailstock Spindle MT2
Main Motor 600W
Voltage/Frequ. 230V/1Ph/50Hz
Length 930mm
Width 390mm
Height 370mm
Weight 65kg
Technical Changes in the frame of product development preser-
ved.
CAPACITIES
HEADSTOCK
FEEDING AND THREADING
COMPOUND AND CARRIAGE
TAILSTOCK
GENERAL
ENGLISH
