www.holzmann-maschinen.at
8. MAINTENANCE
After a period of time, wear in some of the
moving components will occur. This re-
quires adjustment of those components.
The main spindle bearings are adjusted
at the factory. If end play becomes evi-
dent after considerable use, the bearings
should be adjusted.
See Figure 32:
Fasten the slotted nut A on the back of
the spindle, loosen the outer slotted nut
B. Adjust the slotted nut A until all end
play is taken up. The spindle should still
revolve freely. Fasten the slotted nut A
again and tighten the outer slotted nut
B.
CAUTION: excessive tightening or pre-
loading will damage the bearings!
See Figure 33:
The cross slide is tted with a gib strip
C and can be adjusted with screws D t-
ted with lock nuts E. Loosen the lock nuts
and tighten the set screws until the slide
moves freely without play.
Tighten lock nuts to retain the adjust-
ment.
See Figure 34:
The top slide is tted with a gib strip F
and can be adjusted with screws G tted
with lock nuts H. Loosen the lock nuts
and tighten the set screws until the slide
moves freely without play.
Tighten the lock nuts H to retain this ad-
justment.
See Figure 35:
The half nut engagement can be adjusted
with screws I tted with lock nuts J.
WARNING
!
Never attempt to perform any mainte-
nance, checks, repairs etc . whilst ma-
chine is turned on.
Disconnect the machine from the power
supply prior to any activities.
MAIN SPINDLE BEARINGS
ADJUSTMENT OF CROSS SLIDE
ADJUSTMENT OF TOP SLIDE
See Figure 35:
The half nut engagement can be adjusted
with screws I tted with lock nuts J.
Loosen the nuts on the right side of the
apron and adjust the control screws unitl
both half nuts move freely without play.
Tighten the nut.
LATHE MUST BE SERVICED AT ALL LUB-
RICATION POINTS AND ALL RESERVOIRS
FILLED UP TO OPERATING LEVEL BEFORE
THE LATHE IS PLACED INTO SERVICE!
FAILURE TO COMPLY MAY CAUSE SERI-
OUS DAMAGE!
1. Carriage - See Figure 36
Lubricate the four oil ports A with 20W
machine oil once a day
2. Cross slide - See Figure 36
Lubricate the two oil ports B with 20W
machine oil once per day.
3. Leadscrew - See Figure 37
Lubricate the left oil port C and the right
oil port D with 20W machine oil once per
day.
Do not remove the metal chips with your
bare hand. There is a risk of cutting inju-
ry due to sharp edged chips.
Never use ammable solvents or cle-
aning agents that generate noxious fu-
mes! protect electrical components such
as motors, switches, boxes etc. against
humidity when cleaning.
After operation, clean all chips and clean
the machine, apply tool oil to prevent
rusting.
In order to maintain the machining ac-
curacy, take care of the center, the sur-
face of the machine tool for the chuck
and the guide way and avoid mechanical
damage and the wear due to improper
guide.
REPAIR WORK MAY ONYL BE CARRIED BY
QUALIFIED PERSONNEL ONLY;
ADJUSTMENT OF HALF NUT GUIDE
LUBRICATION
CLEANING
ENGLISH
