METALLDREHMASCHINE / METAL TURNING LATHE ED 750FD
1 1 .2 Technical data
max. Diameter above the machine bed 250 mm
max. Swing over cross slide
150 mm
Distance between centers 750 mm
Width of bed 135 mm
Spindle bore 21 mm
Spindle taper MK 3
Spindle speed ˝I˝ 50 - 1250 min
-1
Spindle speed ˝II˝ 100 – 2500 min
-1
Longitudinal feed 0,07 ~ 0,2 mm/U
Tailstock taper MK 2 / MT 2
Thread pitch metric 0,4 ~ 3,5 mm/U
Thread pitch in inch 8 ~ 56 TPI
Dimensions (LxWxH 1350 x 480 x 550 mm
Weight (net) 126 kg
Mains voltage / frequency 230V / 50Hz
Motor power S1 / S6 0,73 kW / 1,0 kW
