HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at Strana 27
STOLNÍ A ZRACOVACÍ PILA / COMPOUND TABLE/MITRE SAW TK 305
Table saw
6
Table orientation plate
11
Upper blade guard
21
Mitre control angle knob
7
Rip fence
12
Lower blade guard
22
U-shape support pole
8
Safety push stick
13
Blade guard support
23
Blade key
9
Dust bag
14
Safety bolt
24
6mm hex key
10
Upper lock knob 2
16
Clamp groupware
25
5mm hex key
