STOLNÍ A ZRACOVACÍ PILA / COMPOUND TABLE/MITRE SAW TK 305
No.
Specification
Qty
No.
Specification
Qty
1
screw ST4*16
11
98
screw M4*16
2
2
back cover
1
99
LED assembly cover
1
3
Decorative board
1
100
lampshade
1
4
screw M5x27
8
101
Condenser
1
5
housing
1
102
battery cover
1
6
stator assembly
1
103
LED circuit board
1
7
screws ST5x65
2
104
Laser spring
1
8
Bearing 629
1
105
Laser spring
1
9
Brush holder
2
106
copper contact sheet
2
10
Brush
2
107
Battery spring
2
11
Armature assembly
1
108
LED assembly kit
1
12
Bearing 6201
1
109
LED switch
1
13
Push handle
1
110
handle cover
1
14
O type rubber ring 11x1.9
1
111
upper handle
1
15
push
1
112
electromagnetic switch
1
16
Wind ring
1
113
capacitor
1
17
gasket 2
1
114
Overload protection device
1
18
Woolens cushion sheet
1
115
switch HY15
1
19
Frame
1
116
lower handle
1
20
cutting knife
1
117
screw ST4*20
5
21
Guide pin clamping rod
2
118
Three core cable
1
22
With the knife plate plate
1
119
clamp
1
23
screw M6X16
6
120
Rocker locking wheel cover
1
24
Selling spring
1
121
Rocker locking handwheel
1
25
Selling baffle
1
122
Plate washer
1
26
Barrier screw
1
123
lock nut M12
2
27
bearing 608
1
124
Mat 12
2
28
Shaft ring 17
1
125
12 wave pad
1
29
Gear
1
126
Frame clamping pad
1
30
Shaft ring 20
1
127
Torsion spring
1
31
Circlips for holes 42
1
128
Rocker antifriction sheet
1
32
bearing 6004
1
129
SCREW st4*10
2
33
bearing seat
1
130
screw M6*40
1
34
Flat key 6x6x12
1
131
screw M6
3
35
Spindle
1
132
Pitch axis
1
