HOLZMANN MASCHINEN GmbH www.holzmann-maschinen.at Strana 47
STOLNÍ A ZRACOVACÍ PILA / COMPOUND TABLE/MITRE SAW TK 305
36
screw M4*12
5
133
Rocker angle label
1
37
push rod shaft screw
1
134
rocking bar
1
38
Hook spring
1
135
Rocker cover
1
39
handle assembly
1
136
Mount antifriction sheet
1
40
opening ring 5
2
137
Rocker pointer
1
41
Shield shaft screw
1
138
screw M6*22
2
42
Loosen lock button
1
139
screw M8*25
3
43
movable shield assembly
1
140
adminiculum
1
44
Shaft ring 48
1
141
Bearing pin
1
45
lower splint
1
142
Auxiliary protective cover
1
46
blade 305
1
143
disk cleading
1
47
Splint
1
144
disk screw
1
48
Saw blade clamping washer
1
145
disk
1
49
Inner six angle screw M8x18
(left)
1
146
disk finger
1
50
Cover of frame
1
147
Positioning handle screw
1
51
screw M5*20
4
148
swing handle
1
52
serew M4*55
2
149
lock nut M6
1
53
junction box cover
1
150
fixed position hand shank spring
1
54
Push rod
1
151
disk fixed position spanner
1
55
Switch
1
152
disk Sealing plate
1
56
Inductance
1
153
screw M5*10
5
57
Terminal
3
154
Shim
1
58
cable clip
1
155
swing handle head
1
59
plug
1
156
O type rubber ring 3.55*1.8
1
60
cable jacket
1
157
steel 6
1
61
Wiring terminal
1
158
disk locking lever spring
1
62
Guide pillar gripping
handwheel.
2
159
Disk locking lever
1
63
Guide pin clamping ring.
2
160
opening ring 10
1
64
lock nut M8
2
161
locking lever pressing plate
1
65
Guide pin clamping pad
2
162
Disk friction sheet
4
66
guide pillar
1
163
clamping rod
1
67
Promotion Board
1
164
Workpiece clamping wheel
1
68
screw M4*8
23
165
clamping knob
4
69
leading column
1
166
clamping arm
1
70
Table plate
1
167
clamping disc
1
