Honda Electronics HE-51C - Brightness and Sweep Speed Settings






7-2-2. MENU 1












 Press

key. [MENU 1] is shown.
 Select “LIGHT” with key.


Select brightness of screen with key.
2
N
ote 1) When you use the unit at Maximum brightness using internal batteries, operating time wil
l
be
decreased about 10-20 percent even if new batteries are used.
N
ote 2) If the unit becomes high temperature, it’s brightness decreases automatically to protect the
L
CD. It is not trouble.
1
It adjusts brightness of screen.
LIGHT : D,･,･,･,B
Bri
g
htness
Sweep Speed


On fish finder, the newest display (display just under the boat) is shown on the right edge o
f
screen. At the same time, previous display moves leftward. Display of fish finder i
s
formed by repeating such movement. Sweep speed is speed that display forwards. Displa
y
varies depending on it’s setting. If you set the sweep speed to “Fast”, you can recognize the
undulated bottom easily. If you set it to “Slow”, you can see long-time image.
【Relation of sounding rate and sweeping speed】
6 ranks of sweeping speed can be selected on menu. Ratio of sweeping speed vs. soundin
g
rates at each set value is shown on below table. At S setting, sweeping speed is high, 3000
times/min. at maximum. It enables to show the bottom in details.
It sets sweeping speed.
SWEEP: STOP, 1, 2, 3, 4, S













Max.S.R.permiunuteSet
Va lu e
S.S/
S.R.
Bsttery Ext.Battery
S 1/1 Apr.3000 Apr.3000
4 1/1 Apr.1200 Apr.1700
3 1/2
Apr.1200
Apr.1700
2 1/4
Apr.1200
Apr.1700
1 1/8
Apr.1200
Apr.1700
STOP -- -- --

18

1
Press

key. “MENU 1” is shown. Select
SWEEP” with

of cross key.

Set Sweep Speed with

key.




2




If Sweep Speed is set to “Freeze”, fish finder’ image displayed at that time
remains. If you continue to operate boat, different information from actua
l
situation is shown. It is very risky.



N
ote 1) Maximum sounding rates per minute extremely varies depending other settings which you ar
e
using (Depth setting, MENU setting and Expansion mode).
N
ote 2) At S setting, bottom nature distinction does not work even if it sets to ON.
N
ote 3) When you use the unit at S setting using internal batteries, operating time will be decrease
d
about 10-20 percent even if new batteries are used.


